ATN BlazeSeeker 207 Thermal Monocular 12 Micron

Product #: ASTIMNBLS207 UPC: 658175124672 Mfg Part #: TIMNBLS207

$494.44

$579

SAVE $84.56
Share:
Overview

The ATN Blaze Seeker 207 is equipped with a high-quality thermal sensor offering a 256x192 (25 Hz) resolution, 12 μm pixel size, and a low NETD rating of <35mK for enhanced temperature sensitivity and improved image clarity.

Choose from five color palettes for a custom viewing experience: White Hot, Black Hot, Rainbow, Iron Red, and Alarm.

Offers integrated features for capturing still images and recording video, with the option to save media on a MicroSD card with up to 256GB of storage.

Connect the monocular wirelessly to your smartphone and app to adjust settings, capture photos, or record thermal videos directly from your phone.

Adjust the monocular for different users using the diopter adjustment wheel, ensuring a clear and sharp image for each viewer.

Easily fits in a pocket for convenient portability, allowing you to take it anywhere you go.

Built-in rechargeable battery with up to 9 hours of operation time and external power supply option.

Specifications
Battery Count
1
Battery Run Time
9 hr
Battery Type
Rechargeable
Brand
ATN
Brand Family
Blaze Seeker
CA Prop 65
Yes
Color
Black
Condition
New
Country of Origin
USA
Material
Aluminum
Optics App Support
ATN Blaze App
Optics Class
Thermal Imaging
Optics Finish
Anodized
Optics Length
5.9''
Optics Mounting System
Not Included
Optics Objective
7
Optics Shockproof
Yes
Optics Type
Thermal Handheld Monocular
Product Class
Thermal Optics
Thermal Bluetooth
Yes
Thermal Core
ATN Obsidian Core LT
Thermal Detector Type
12um Uncooled 50 Hz
Thermal Diopter Adj
Yes
Thermal Display / Monitor Type
LCOS
Thermal Display Resolution
256 x 192
Thermal Eye Relief
12.5mm
Thermal FOV Deg
24° x 18°
Thermal Human Detect Range
345 yds
Thermal Human ID Range
38
Thermal Imaging Palettes
White Black & Green Hot / Iron Red / Alarm / Sepia
Thermal Objective Lens (Focal Length)
75 mm; F1.2
Thermal Operating Temperature
-4°F to +131°F / -20°C to 55°C
Thermal Optics Wi-Fi
Yes
Thermal Power Supply
Charging USB Type C
Thermal Recording Type
On-Board Video and Still Images
Thermal Sensor Frame (Refresh) Rate
50 Hz
Thermal Sensor Pixel Interval
12 um
Thermal Sensor Resolution
256 x 192
Thermal Snapshot Capture
Yes
Thermal Standby Mode
Yes
Thermal Storage
256 GB
Thermal Video Recording Resolution
800x600
Warranty
Mfg 3 Year Limited
Waterproof
IP67
Weight
9.6 oz
